| Brand Name: | EcooGraphix |
| Payment Terms: | T/T |
Specifications
| Type | ECOO-IN-F |
|
Features |
Printing speed: 8,000rph-10,000rph Environment friendly Good water/ink balance Rich in printing layer |
| Packing | 2.5 kg/tin, 6 tins/carton |
| Shelf Life | 3 years(from the production date); product against light and water |
|
Application |
ECOO-IN-F printing ink is suitable for printing packaging, advertisement, label, brochures and decorating products on art paper, coated paper, offset paper, cardboard, etc., especially suitable for single-color and multi-color printing. |
| ITEM/TYPE |
TACK VALUE |
FLUIDITY (mm) |
PARTICLE SIZE (μm) |
SETTING TIME (min) |
DRYING TIME (hr) |
SKINNING TIME (hr) |
|
F YELLOW |
6-7 |
35±1
|
15 | 4 | < 10 | >15 |
|
F MAGENTA |
5.5-6.5 |
34±1
|
15 | 4 | < 10 | >15 |
|
F CYAN |
6.5-7.5 |
35±1
|
15 | 4 | < 10 | >15 |
|
F BLACK |
7-8 |
35±1
|
15 | 4 | < 10 | >15 |
| Tack Value | The value is measured in 1 minute by inkometer at 32℃ and 400rpm. | |||||
| Set Time | Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc | |||||
| Condition of test | Room temperature 25℃, humidity 65%-75% | |||||
| ITEM/TYPE |
Light Resistance |
Heat Resistance |
Acid Resistance |
Alkaline Resistance |
Alcohol Resistance |
Soap Resistance |
|
F YELLOW |
4 | 5 | 5 | 4 | 4 | 4 |
|
F MAGENTA |
3 | 5 | 5 | 5 | 4 | 5 |
|
F CYAN |
7 | 5 | 5 | 5 | 5 | 5 |
|
F BLACK |
7 | 5 | 5 | 5 | 5 | 5 |
| Light Fastness | 1-8 (weak-strong) | |||||
| Others | 1-5 (weak-strong) | |||||
